Fully support Android 14, Ubuntu 2004/2204, Linux, Kylin v10, Star Kylin, and OpenHarmony ARM systems
DC_M566 is an RK3566 B2B board-to-board expansion development kit, which provides multiple display functions, such as: 1 EDP2K port, 1 HDMI4K port, 1 LVDS 1080P port, and 1 MIPIDSI 1080P port. It is equipped with 1 Gigabit Ethernet port on-board, supports the expansion of MINI PCIE 4G Internet of Things (IoT), and provides dual fan sockets (12V/5V). In addition, it also has 6 USB ports on-board (including 1 TYPE-C USB OTG port), four serial ports (including 2 RS-232 ports, 1 RS-485 port, and 1 TTL port), and 1 ADC/KEY port.
1. Offers core board and development kit resources for customers' secondary hardware development. 2. 1TOPS NPU for neural network inference and acceleration, suitable for embedded development. 3. AI algorithm API available on delivery, 35+ commercializable algorithms for secondary development. 4. B2B form with firm interfaces, ideal for industrial, healthcare, and commercial display all-in-ones. 5. Enterprise-level technical support.
Quad-core 64-bit Cortex-A55, with a maximum clock speed of 1.8GHz
GPU
ARM G52 2EE, supporting OpenGL ES 1.1/2.0/3.2, OpenCL 2.0, Vulkan 1.1, and featuring high-performance 2D acceleration hardware
Memory
LPDDR4X 1GB/2GB/4GB
Flash Memory
EMMC 8G/16G/32G/64G (optional)
Memory Expansion
Supports up to 128GB TF card expansion
Display Interfaces
Specification
HDMI OUT Interface
1 port, HDMI2.0 with a maximum supported resolution of 4096x2160@60Hz
LVDS Interface
1 port, LVDS interface (single-channel, 6-bit dual-channel, 8-bit dual-channel), with a maximum supported resolution of 1920×1080@60Hz
EDP Interface
1 port, with a maximum supported resolution of 2560×1600@60Hz
MIPI DSI Interface
1 port, with a maximum supported resolution of 1920×1080
Audio Interfaces
Specification
Headphone Jack Interface
1 mono microphone input (analog signal input), 1 stereo audio output (analog signal output)
Power Amplifier Interface
Left and right stereo output, supporting 8Ω 10W dual speakers
Microphone Interface
1 stereo microphone input (analog signal input)
Network Type
Specification
Ethernet
1 standard RJ45 interface, 10/100/1000M adaptive Ethernet
WIFI/Bluetooth
Onboard WIFI/BT module, supporting WiFi 2.4GHz/5GHz (5GHz optional), 802.11a/b/g/n/ac protocols, and Bluetooth 4.0 (supporting BLE)
Mobile Network
1 built-in MINI PCI_E socket for expanding and connecting 3G/4G modules
Basic Interfaces
Specification
USB2.0
4 USB Host interfaces (1 external standard double-layer USB socket upper layer, 3 2.0mm - 4P sockets) for connecting devices such as high-definition USB cameras, USB flash drives, keyboards, and mice
USB3.0
1 USB Host interface (1 external standard double-layer USB socket lower layer) for connecting devices such as high-definition USB cameras, USB flash drives, keyboards, and mice
USB OTG
1 USB OTG interface (standard Type C interface) for system debugging, firmware updating, and can also be set to Host mode
Serial Ports
4 serial ports, including 2 RS232 serial ports, 1 RS485 serial port, and 1 TTL debugging serial port
GPIO Pins
5 IO pins, supporting input and output operations, and can also be multiplexed as a two-wire SPI interface
Onboard RTC
Supports real-time clock, powered by a 1220 coin cell battery
Timed Power On/Off
Supported
IIC Interface
1 standard I2C interface, which can be used for touch and communication
Infrared Receiver
1 infrared receiver, supporting infrared remote control function
